Connect AstrBot to WeChat Official Account Platform

AstrBot supports WeChat Official Account integration (version >= v3.5.8). After setup, you can chat with AstrBot directly in the WeChat Official Account chat interface.

Before You Start

1. Open AstrBot Dashboard.
2. Click Bots in the left sidebar.
3. Click + Create Bot.
4. Select weixin_official_account.

A configuration dialog will appear. Keep it open and continue.

Create / Sign In to WeChat Official Account Platform

Open WeChat Official Account Platform.

• If you already have an account, sign in.
• If not, register a new account and choose Official Account.

Note

A newly registered account may require 1-2 days for review before it can be used.

Configure Callback Service

Open Settings & Development -> Development Interface Management.

Copy AppID and AppSecret from WeChat platform to AstrBot fields appid and secret.

Open IP whitelist and add your public IP(s), one per line if multiple.

In server configuration, click modify.

• Token: create any string with length 3-32, and fill the same value in AstrBot token.
• EncodingAESKey: click random generate and fill AstrBot encoding_aes_key.

Keep Unified Webhook Mode (unified_webhook_mode) enabled (recommended), then save AstrBot config and wait for restart.

For URL:

• If unified mode is enabled, use the unique callback URL generated by AstrBot (from logs or bot card).
• If unified mode is disabled, use http://<your-domain>/callback/command.

Note

WeChat Official Account callback supports only ports 80 or 443. You usually need a domain and reverse proxy:

• Unified mode enabled: forward to AstrBot port 6185
• Unified mode disabled: forward to adapter port 6194

Set message encryption mode to Security Mode.

Wait a moment and click Submit. If configuration is correct, you will see success.

Test

In WeChat Official Account platform, open account profile and find your QR code.

Scan it with WeChat, send help, and check whether AstrBot replies.

If it replies, integration is successful.

Note

If console shows ip xxxxx not in whitelist, your public IP is not in WeChat whitelist yet. Add it and wait a few minutes for WeChat to refresh.

Reverse Proxy (Custom API Base)

AstrBot supports custom endpoint via api_base_url for environments without stable public IP.

Voice Input

Install ffmpeg for voice input support.

• Linux: apt install ffmpeg
• Windows: download from FFmpeg website
• macOS: brew install ffmpeg
